VT-950+
MEDIUM SIZE VERTICAL TURNING CENTER
Built In Gear Box With 24″-32″ Chuck
The machine can handle a variety of complex processes from turning to milling and drilling in one setting. With the rigid structure, this turning center can reduce your machining process and make your work more precise and productive, even for the most toughest materials for various application needs.
- Many different spindle motors to choose from
- Highly rigid travelling column design
- Powerful milling function optional
- Environment-friendly lub-coolant separation design
- Spindle oil cooler with high-pressure lubricant pump equipped standard
Category Vertical CNC Turning Centers
Tags Box way, Driven tools, Fanuc 0i, Gear spindle, Linear guideway
Heavy duty cutting for large workpieces
VT-950 vertical turning center is the ideal machine for your large size applications. With precision hand scraped and grinded guide way system in all axes, the unique one piece machine bed design provides rigidity, built to absorb vibration and best stability. Hwacheon’s advanced air floating system keeps the operation stable and allows for smoothest operations.
Tool magazine with Capto interface
In order to reduce frequent setting up, or for workpieces which require many tools, a second tool magazine is available, from which stationary and also very long tools can be automatically exchanged.
User friendly design, a wide range of optional features
VT-950+ vertical turning centers are designed with the user in mind. The user-friendly machine design and a variety of supplementary features make for stronger, faster, and more precise machining performance.
High dynamism through air floating technology
Despite their high masses, with their rapid traverse speed of 24 m/min, the VT-950+ and the VT-1150+ permit dynamic machining with minimal non-productive time. This is achieved by means of Hwacheon’s perfected air-floating technology, whereby the box guideways are charged with compressed air. This significantly reduces the stick-slip effect and the break loose torque during start-up.
Specifications
Mechanical specifications
Swing Over Bed [mm] | Ø1100 |
---|---|
Max. Cutting Diameter [mm] | 950 |
Max. Cutting Length [mm] | 850 |
Chuck Size [mm] | 610 |
Max. Spindle Speed [rpm] | 1125 |
Spindle Motor Power [kW] | 30 / 22 |
NC System | Fanuc 0i |
In action
VT-950+ in action
Samples
Processing samples
Software
Processing software
- L-HTLDHwacheon Spindle Displacement Control System
Learn more about Hwacheon processing software
